Product Description

TK561.SG.360.12.S.10.LPP boasting a frequency output up to 300 kHz. With synchronous index output on channel A and optional B, it ensures versatile functionality. Constructed with durable stainless steel shaft, non-corroding aluminum flange, and painted aluminum housing treated for high temperatures, it withstands harsh environments. Operating from -10°C to +70°C, withstanding vibrations up to 10 g and shocks up to 20 g, it’s engineered for reliability.

Additional information

Product Specifications

  • Body diameter (mm) 63.5
  • Flange square flange, servo standard, servo-clip, FRE (REO444)
  • Diameter shaft (mm) 6, 8, 9.52, 10, 11, 11R
  • Resolution (PPR) up to 20.000 ppr, others on demand
  • Output frequency up to 300 kHz
  • Protection class (EN60529) K4, K5, K6
  • Interface LD, LD2, PP2, NPN, PNP

MECHANICAL SPECIFICATIONS

  • Dimensions see drawings
  • Shaft loading axial 200N; radial 200N
  • Shaft Rotation Speed 10.000 RPM to short cycle time; 6000 RPM continuous; 2000 RPM with hole shaft
    proof
  • Starting torque a 25° C 0,025Nm; 0,040Nm whit hole shaft proof
  • Moment of inertia 40g cm²
  • Bearings life 5 x 10^9 revolutions (minimum)
  • Weight ~ 0,56kg

ELECTRICAL SPECIFICATIONS

  • Output frequency up to 300 kHz
  • Sinchronous index output default on channel A; B – A+B Optional
  • Supply current without load 150 mA max
  • Protection short circuit protection (only output LD2 and PP2) against inversion of polarity (except 5Vcc)

MATERIALS

  • Shaft stainless steel
  • Flange aluminium non corroding
  • Housing Aluminium painted with inhibithing treatment 180°C

ENVIRONMENTAL SPECIFICATIONS

  • Operating temperature range -10°C ÷ +70°C
  • Storage temperature range -30°C ÷ +85°C
  • Relative humidity 98% RH without condensing
  • Vibrations 10 g (from 10 up to 2.000 Hz)
  • Schock 20 g (for 11 ms)

ORDERING CODE

TKXXX TYPE

TK51   unidirectional

TK511   undirect.+ index

TK560   bidirectional

TK561   bidirez.+ index
XXX ASSEMBLY

F Flange Servo

SG Servo-Clip

FRE Flange REO
XXXX PULSE RATE

2 – 5 – 10 – 20 – 25 – 30 – 32 – 36 – 40 – 50 – 60 – 64 – 72 –
80 – 88 – 90 – 100 – 120 – 125 – 127 – 128 – 150 – 162 –
180 – 183 – 200 – 240 – 250 – 254 – 256 – 300 – 314 – 360 –
375 – 390 – 400 – 500 – 512 – 576 – 600 – 625 – 635 – 720 –
750 – 800 – 900 – 1000 – 1024 – 1200 – 1250 – 1270 –
1440 – 1500 – 1800 – 2000 – 2048 – 2500 – 2540 – 2700 –
3600 – 4096 – 5000 – 9000- 10.000.
up to 20 000 ppr on demand
XXXXX VOLTAGE SUPPLY

5 +5V ±5%

11/30 +11V ÷ 30V

24/5 +11/30V +5V output
X OUTPUT FREQUENCY

S from 0 up to 100kHz

V from 0 up to 300kHz
XX PROTECTION CLASS

K4 IP 64 (EN60529)

K5 IP 65 (EN60529)

K6 IP 66 (EN60529)
XX,nn SOLID SHAFT

6               Ø 6mm (Flange F – SG)

8               Ø 8mm (Flange F – SG)

9,52          Ø 9,52mm (Flange F – SG)

10             Ø 10mm (Flange F – SG)

11             Ø 11mm (Flange FRE – F – SG)

11R           Ø 11mm (Flange FRE)
XXnn ELECTRICAL CONNECTIONS

OUTPUT        S; P; OC; OP; PP2; LD; LD2 (except TK561)

Pnn                  on axial cable gland with cable from 1 up to 6m long

PLnn               radial cable gland with cable 1 up to 6m long

S07                 on 7 pins axial MIL connector

L07                 on 7 pins radial MIL connector

OUTPUT        LD; LD2 (only TK561)

Pnn                 on axial cable gland with cable from 1 up to 6m long

PLnn               radial cable gland with cable 1 up to 6m long

S10                 on 10 pins axial MIL connector

L10                 on 10 pins radial MIL connector

R1                   on 12 pins radial “contact” connector

nn                    cable length (es. PL10 = 1m. … PL60 = 6m)
XXX-XXXX OUTPUT CIRCUITS

S                 NPN standard (resistor included)

OC              NPN open collector

P                 PNP (resistor included)

OP              PNP open collector

PP2-5         Push-Pull 5 V output

PP2-1130   Push-Pull 11/30 V output (only with voltage supply 11/30 V)

LD              Line driver RS422 (26LS31) only 5V or 24/5V

LD2-5         Line driver 5 Vcc output

LD2-1130   Line driver 11÷30 Vcc output  (only with voltage supply 11/30 V)
Xnnn
CUSTOM
