1LE5503-3AB79-0AB1-Z B02+L51+M1Y
- Payment by invoice possible
- Not currently in stock, contact us for factory lead times
- Payment by invoice possible
- In stock at factory, ready to ship in estimated 1-2 weeks, contact us for expedited options
- Del Rey is proud to be the exclusive distributor of iLumiGlo products
- Del Rey is proud to be the exclusive distributor of Waagene products
- Payment by invoice possible
- Low quantities typically kept on hand; please contact us for availability at lead time
- Authorized MiniBOOSTER distributor & hydraulic excellence partner
Product Description
SD motor type: 1CV3317B low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) gray cast iron housing Basic Line Premium Efficiency IE3, 4-pole * size 315L* 315 kW (50 Hz) standard color RAL 7030 if no order code is specified for selecting another color. The product will be delivered with either the Siemens or Innomotics product brand. NON-STANDARD-WINDING 3 AC ..HZ, …V, …KW IM B 3, 3 PTC thermistors for disconnection (2 terminals) terminal box base right with terminal box at top B02=Acceptance test certificate 3.1 according to EN 10204 L51=Bearing insulation NDE (non drive end)
Additional information
Specifications
- M1Y: 480VD_50HZ_315kW
- IEC squirrel-cage rotor, self-cooled, IP55
- Temperature class 155(F) according to 130(B)
- Gray cast iron housing Basic Line
- Premium Efficiency IE3, 4-pole * size 315L
- 315kW (50 Hz)
- 3 AC 50HZ, 480VD
- IM B 3
- 3 PTC thermistors for disconnection (2 terminals)
- B02= Acceptance test certificate 3.1 according to EN 10204
- L51= Bearing insulation NDE
Product Information
| Article Number | 1LE5503-3AB79-0AB1-Z B02+L51+M1Y |
|---|---|
| Lifecycle (PLM) | PM300:Active Product |
| Metal Factor | N-W—– |
| EAN | Not available |
| UPC | Not available |
| Commodity Code | 85015381 |
| LKZ_FDB/CatalogID | GG_LD |
| Product Group | 2679 |
| Group Code | P113 |
Classifications
| Version | Classification | |
|---|---|---|
| eClass | 12 | 27-02-21-01 |
| eClass | 6 | 27-02-21-01 |
| eClass | 7.1 | 27-02-21-01 |
| eClass | 8 | 27-02-21-01 |
| eClass | 9 | 27-02-21-01 |
| eClass | 9.1 | 27-02-21-01 |
| ETIM | 7 | EC001851 |
| ETIM | 8 | EC001851 |
| ETIM | 9 | EC001851 |
