Bosch Filter part-number 1 687 434 062

Injection Oiler 501 with Adjustable Metering Quantity

Contact us for Pricing
Availability: Out of stock Category: Tag:
  • Payment by invoice possible
  • Not currently in stock, contact us for factory lead times
  • Payment by invoice possible
  • In stock at factory, ready to ship in estimated 1-2 weeks, contact us for expedited options
  • Del Rey is proud to be the exclusive distributor of iLumiGlo products
  • Del Rey is proud to be the exclusive distributor of Waagene products
  • Payment by invoice possible
  • Low quantities typically kept on hand; please contact us for availability at lead time
  • Authorized MiniBOOSTER distributor & hydraulic excellence partner

Product Description

Metering pumps dispense lubricants in precise quantities, typically ranging from 3 to 30 mm3. These piston-driven pumps allow for partial adjustment of the delivery rate. Initially set to maximum capacity at the manufacturing plant, the delivery volume can be decreased by turning the setting sleeve counterclockwise. Lubricant can be sourced from a central reservoir, a standalone container, or a pressurized oil line. Metering elements can be activated individually or collectively as needed.

Additional information

Specifications

  • Optimal metering of every lubrication point regardless of line lengths and cross sections
  • Metering elements can be actuated individually or in groups
  • Splash lubrication through high oil acceleration
  • Fast sequence of pulses: up to 120 pulses per minute
  • Space-saving design
  • Eco-friendly: no oil in the exhaust air

Applications

  • Air oiling (assembly tools)
  • Chain lubrication

Technical Data

Function Principle Injection Oiler
Outlets 1 or 3
Metering Quantity 3-30 mm³/stroke
Lubricant Oil
Operating Viscosity 10-1100 mm²/s
Actuating Air Pressure 3-10 bar (43-145 psi)
Operating Temperature -10 to +80 °C (+14 to 176 °F)
Max. Perm. Flow Rate at 6 bar 200 l/min
Mounting Position Oil duct vertical

Order Information

Version Part Number For Tube Diameter [mm] Sealing Description
1-port type 501-301-000 2.5 NBR Individual use, can be coupled to further 1- and 3-port-injection oilers. Basis unit for injection oiler with reservoir.
501-301-008 2.5 FPM
501-301-024 4 NBR
501-301-024-VS 4, quick connector NBR
501-301-025 4 FPM
501-301-053 4, quick connector NBR
3-port type 501-303-000 2.5 NBR Group actuation
501-303-008 2.5 FPM Group actuation
501-303-024 4 NBR Group actuation
501-303-024-VS 4, quick connector NBR Group actuation
501-303-025 4 FPM Group actuation
501-303-053 4, quick connector FPM Individual actuation
501-303-001* 2.5 NBR Group actuation
501-303-037 4 NBR Individual actuation, piston monitoring
501-303-038 4 NBR Group actuation, piston monitoring

Manuals and Data Sheets

Brochures

Technical Data Sheet
