SOL CART VALVE 2/2NC
$531.90
- Payment by invoice possible
- Not currently in stock, contact us for factory lead times
- Payment by invoice possible
- In stock at factory, ready to ship in estimated 1-2 weeks, contact us for expedited options
- Del Rey is proud to be the exclusive distributor of Waagene products
- Payment by invoice possible
- Low quantities typically kept on hand; please contact us for availability at lead time
- Authorized miniBOOSTER distributor & hydraulic excellence partner
Product Description
Introducing Parker’s SOL CART VALVE 2/2NC N.America Only: a powerful and versatile solenoid valve that offers efficient flow control with options for both normally-closed and normally-open configurations. With flow capacities up to 75 lpm (20 gpm) and high pressure capabilities up to 350 bar (5000 psi), it’s the perfect choice for a wide range of industrial applications.
Additional information
Product Specifications
| Part Number | GS022700V | Brand | Parker |
| Configuration | Normally Open | Division | Hydraulic Cartridge Systems Division |
| Function | 2-way | Wire Mesh Screen Included | No |
| Seal Material | Fluorocarbon | Valve Material | All parts steel. All operating parts hardened steel |
| Maximum Operating Pressure | 350 bar | 5000 psi | Flow Rate | 5 GAL/MIN, 19 L/MIN | 5 Gal/min | 19 L/min |
| Leak Rate | 82 CC/min @ 3000 PSI (210 BAR) cm3/min | Maximum Flow Rate | 5 Gal/min | 19 L/min |
| Maximum Inlet Pressure Rating | 350 bar | 5000 PSI, 350 BAR | 5000 psi | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Cavity Size | C09-2 | Maximum Operating Temperature | +204 °C | +400 °F |
| Minimum Operating Temperature | -26 °C | -15 °F | Operating Temperature | -26 to +204 °C | -15 to +400 °F |
| Response Time | 50 ms | Installation Torque | 22 lb-ft | 30 Nm |
| Coil Nut Tightening Torque | 3 lb-ft | 4.1 Nm | Actuation Type | Electrical |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Mounting Type | Screw in cartridge valve |
| Coil Type | 1/2″ Super Coil | Operation Type | Solenoid operated |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Input Voltage | 85% of rated voltage at 72°F (20°C) min |
| Weight | 0.31 kg | 0.14 lb |
