RAH081S10 PTC Pressure Guard Valve7-70 Bar
$527.11
- Payment by invoice possible
- Not currently in stock, contact us for factory lead times
- Payment by invoice possible
- In stock at factory, ready to ship in estimated 1-2 weeks, contact us for expedited options
- Del Rey is proud to be the exclusive distributor of Waagene products
- Payment by invoice possible
- Low quantities typically kept on hand; please contact us for availability at lead time
- Authorized miniBOOSTER distributor & hydraulic excellence partner
Product Description
Upgrade your hydraulic system with Parker’s RAH081S10 PTC Pressure Guard Valve! These top-of-the-line valves excel in continuous duty applications, maintaining stability with minimal pressure loss. Able to handle exceptional pressures up to 420 bar (6000 psi) and flows up to 400 lpm (106 gpm), you won’t find a better option for optimizing your hydraulic system.
Additional information
Product Specifications
| Part Number | RAH081S10 | Brand | Parker |
| Configuration | Pressure Relief | Division | Hydraulic Cartridge Systems Division |
| Function | Pilot Operated | Seal Material | D-Ring (Standard) |
| Valve Material | All parts steel. All operating parts hardened steel | Adjustment Mechanism | Screw |
| Maximum Tank Pressure | 350 bar | 5000 psi | Standard Setting Pressure | 34.5 bar | 500 psi |
| Maximum Operating Pressure | 350 bar | 5000 psi | Reseat Pressure | 90% of pressure setting |
| Pressure Control Range | 100-1000 PSI, 6.9-69 BAR | 6.9-69 bar | 100-1000 psi | Flow Rate | 20 Gal/min | 20 GAL/MIN, 75.8 L/MIN | 75.8 L/min |
| Maximum Flow Rate | 20 Gal/min | 75.8 L/min | Leak Rate | 5 per @ 100 psi (6.8 bar) setting cm3/min |
| Maximum Inlet Pressure Rating | 350 bar | 5000 PSI, 350 BAR | 5000 psi | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Pressure Control Sensitivity | 19.6 per turn bar | 285 per turn psi | Maximum Pressure Setting | 69 bar | 1000 psi |
| Cavity Size | C08-2 | Minimum Operating Temperature | -35 °F | -37 °C |
| Maximum Operating Temperature | +93 °C | +200 °F | Operating Temperature | -35 to +200 °F | -37 to +93 °C |
| Installation Torque | 32-36 lb-ft | 43-49 Nm | Mounting Type | Screw in cartridge valve |
| Actuation Type | Pressure Sensing | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Operation Type | Automatic | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Weight | 0.09 kg | 0.2 lb |
