PTC sequence valve 7-69 bar
$610.44
- Payment by invoice possible
- Not currently in stock, contact us for factory lead times
- Payment by invoice possible
- In stock at factory, ready to ship in estimated 1-2 weeks, contact us for expedited options
- Del Rey is proud to be the exclusive distributor of Waagene products
- Payment by invoice possible
- Low quantities typically kept on hand; please contact us for availability at lead time
- Authorized miniBOOSTER distributor & hydraulic excellence partner
Product Description
Parker’s pilot operated sequence valves in North America are designed to allow multiple actuators to work in sequence based on pressure settings. They can be internally or externally piloted, and work with flows up to 152 lpm (40 gpm) and pressures up to 380 bar (5500 psi).
Additional information
Product Specifications
| Part Number | SVH161S10 | Brand | Parker |
| Rated Flow (gpm) | 40 | Pressure Range Adjustment (psi) | 100-1000 |
| Division | Hydraulic Cartridge Systems Division | Function | Pilot Operated Sequence |
| Pilot Location | Internal | Seal Material | Nitrile |
| Valve Material | All parts steel. All operating parts hardened steel | Adjustment Mechanism | Screw |
| Drain Option | External | Pilot Option | Internal |
| Maximum Tank Pressure | 350 bar | 5000 psi | Maximum Operating Pressure | 380 bar | 5500 psi |
| Standard Setting Pressure | 34.5 bar | 500 psi | Reseat Pressure | 80% of set pressure |
| Pressure Control Range | 6.9-69 bar | 100-1000 psi | Flow Rate | 40 Gal/min | 151.6 L/min |
| Maximum Drain Flow Rate | 1.87 Gal/min | 0.5 L/min | Leak Rate | 5 per 100 PSI (6.8 BAR) setting cm3/min |
| Maximum Flow Rate | 40 Gal/min | 151.6 L/min | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Maximum Inlet Pressure Rating | 380 bar | 5500 psi | Pressure Control Sensitivity | 23 per turn bar | 334 per turn psi |
| Maximum Pressure Setting | 69 bar | 1000 psi | Cavity Size | 6-3 |
| Minimum Operating Temperature | -34 °C | -30 °F | Maximum Operating Temperature | +250 °F | +121 °C |
| Operating Temperature | -30 to +250 °F | -34 to +121 °C | Installation Torque | 73 lb-ft | 99 Nm |
| Mounting Type | Threaded Cartridge Valve | Actuation Type | Pressure Sensing |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Adjustment Type | Screw |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Weight | 0.45 kg | 1 lb |
