Product Description
Discover Parker’s versatile pressure-compensated flow controls, designed to maintain a consistent flow amidst changing loads and pressures. With the capability to handle pressures up to 420 bar (6000 psi) and flows up to 56 lpm (15 gpm) in a single common cavity, these controls are ideal for a variety of North American applications.
Additional information
Product Specifications
| Part Number | FR101S065 | Brand | Parker |
| Flow Rate Accuracy | 30% | Configuration | Partial Reverse Flow |
| Division | Hydraulic Cartridge Systems Division | Function | Flow Control |
| Seal Material | Nitrile | Valve Material | All parts steel. All operating parts hardened steel |
| Adjustment Mechanism | Screw | Maximum Operating Pressure | 245 bar | 3500 psi |
| Flow Rate Display Range | 0.5-0.8 GAL/MIN, 1.9-3 L/MIN | 0.5-0.8 Gal/min | 1.9-3 L/min | Maximum Flow Rate | 7 GAL/MIN, 26.5 L/MIN | 6 Gal/min | 22.5 L/min |
| Flow Rate | 6 Gal/min | 22.5 L/min | Maximum Inlet Pressure Rating | 245 bar | 3500 psi |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Cavity Size | C10-2 |
| Operating Temperature | -30 to +250 °F | -35 to +121 °C | Minimum Operating Temperature | -30 °F | -35 °C |
| Maximum Operating Temperature | +250 °F | +121 °C | Installation Torque | 22 (Aluminum), 65 (Steel) Nm | 16 (Aluminum), 48 (Steel) lb-ft |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Operation Type | Manually operated |
| Actuation Type | Pressure Compensated | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Weight | 0.23 kg | 0.5 lb |
