PRH081S50 Pressure Reducing Valve 7-345 Bar
$323.18
- Payment by invoice possible
- Not currently in stock, contact us for factory lead times
- Payment by invoice possible
- In stock at factory, ready to ship in estimated 1-2 weeks, contact us for expedited options
- Del Rey is proud to be the exclusive distributor of Waagene products
- Payment by invoice possible
- Low quantities typically kept on hand; please contact us for availability at lead time
- Authorized miniBOOSTER distributor & hydraulic excellence partner
Product Description
Introducing the PRH081S50 Pressure Reducing Valve by Parker, designed for precise pressure reduction and regulation. It features a pilot operated design and is suitable for applications requiring controlled pressure. With a maximum flow capacity of 150 lpm (40 gpm) and handling pressures up to 380 bar (5500 psi), this valve is ideal for various industrial uses.
Additional information
Product Specifications
| Part Number | PRH081S50 | Brand | Parker |
| Configuration | Pressure Reducing/Relieving | Division | Hydraulic Cartridge Systems Division |
| Function | Pilot Operated | Seal Material | D-Ring (Standard) |
| Valve Material | All parts steel. All operating parts hardened steel | Adjustment Mechanism | Screw |
| Maximum Tank Pressure | 350 bar | 5000 psi | Standard Setting Pressure | 172 bar | 2500 psi |
| Maximum Operating Pressure | 350 bar | 5000 psi | Pressure Control Range | 13.8-350 bar | 200-5000 PSI, 13.8-350 BAR | 200-5000 psi |
| Flow Rate | 8 Gal/min | 8 GAL/MIN, 30 L/MIN | 30 L/min | Maximum Drain Flow Rate | 0.15 Gal/min | 0.56 L/min |
| Maximum Flow Rate | 8 Gal/min | 30 L/min | Maximum Inlet Pressure Rating | 380 bar | 5500 psi |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Pressure Control Sensitivity | 131.7 per turn bar | 1910 per turn psi |
| Maximum Pressure Setting | 350 bar | 5000 psi | Cavity Size | C08-3 |
| Maximum Operating Temperature | +93 °C | +200 °F | Minimum Operating Temperature | -35 °F | -37 °C |
| Operating Temperature | -35 to +200 °F | -37 to +93 °C | Installation Torque | 32-36 lb-ft | 43-49 Nm |
| Mounting Type | Screw in cartridge valve | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Actuation Type | Pressure Sensing | Operation Type | Automatic |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Weight | 0.11 kg | 0.25 lb |
