Product Description
Introducing BVG4P-1/2LOCK Lockable Vented Ball Valves: These versatile valves, featuring fluoropolymer seals, are ideal for a wide range of industrial applications that demand superior seal material and are available in three series: compact, standard, and lockable.
Additional information
Product Specifications
Part Number | BVG4P-1/2LOCK | Brand | Parker |
Product Type | Ball Valves | Product Series | Standard Series |
Diameter Nominal (DN) | 15 | Connection 1 Thread Size (metric) | G1/2 |
Quantity per Box | 20 | Configuration | 2/2 |
Division | Low Pressure Connectors Europe Division | Function | 2-Way |
Handle | Lockable lever, treated steel | Industry | Industrial Manufacturing Equipment |
Stem Material | NICKEL PLATED BRASS | Nickel Plated Brass | Body Material | NICKEL PLATED BRASS | Nickel Plated Brass |
Stem Seal Material | FPM, double O’ring | Ball Material | Nickel Plated Brass |
Ball Seal Material | PTFE | O-Ring Material | FPM |
Seal Material | PTFE | Seat Material | PTFE |
Specifications Met | DI: 97/23/EC (module PED A – diameters greater than 25 mm) | DI: 2006/42/EC (Machinery Directive) | RoHS | REACH | Region of Origin | Italy |
Operating Pressure | 0 to 40 bar | 0 to 1.4 MPa | Maximum Operating Pressure | 14 bar | 1.4 MPa | 203 psi |
Shape | In-line | 2/2 standard serie in-line ball valve female | Connection Size | G1/2 |
Orifice Size | 15 mm | Product Style | Vented Lockable Female Ball Valve |
Technology | Fluid & Gas Handling | Process Control | Pneumatics | Minimum Operating Temperature | -10 °C | 14 °F |
Maximum Operating Temperature | 212 °F | 100 °C | Operation Type | Lever-operated |
For Fluid Type | Gas | All fluids compatible with the component materials | Oil | Water Vapour | Water | Handle Type | Black long lever (treated steel) |
Actuation Type | Manual | Mounting Type | In-line |
Connection Type | BSPP | Weight | 0.239 kg | 0.5258 lb |
