15P202QHBPKS122 HP Filter W/O BYPASS
Waagene Fuel Purifier WPD-200

15P202QHBPKS122 HP Filter

$1,612.75

Contact us for Pricing
Availability: 100 in stock Category:
  • Payment by invoice possible
  • Not currently in stock, contact us for factory lead times
  • Payment by invoice possible
  • In stock at factory, ready to ship in estimated 1-2 weeks, contact us for expedited options
  • Del Rey is proud to be the exclusive distributor of Waagene products
  • Payment by invoice possible
  • Low quantities typically kept on hand; please contact us for availability at lead time
  • Authorized MiniBOOSTER distributor & hydraulic excellence partner

Product Description

The Parker 15P/30P Series is a compelling high-pressure, all-aluminum filter assembly, packed with diverse options. It boasts an impressive fatigue pressure rating of up to 2,000psi and an exceptional flow rate up to 45gpm.

Additional information

Product Specifications



Part Number 15P202QHBM2KS122 Brand Parker
Product Type Hydraulic Filter Division Engine Mobile Hydraulic and Fuel Filtration Division
Compatible Element 932619Q Seal Material nitrile
Housing Material bowl – impacted aluminum (6061-T6, black powderpainted exterior); head – extruded aluminum (anodized 6061-T6 Options no bypass
Flow Rate 20 GPM (75 LPM) Micron Rating 02Q high collapse microglass (2000 psid)
Bypass Valve Pressure Rating 50 psid (3.5 bar) Pressure Rating 3000 psi (206.9 bar)
Indicator Pressure Setting 50 PSI (3.5 bar) Mounting Style inline
Product Style Hydraulic Filter Maximum Operating Temperature 225 F (107 C)
Indicator Type visual automatic reset Filter Element Type cartridge
For Fluid Type Suitable for use with mineral and vegetable oils, and some synthetic oils. For other fluids, please email Technical Support at HFF.techsupport@support.parker.com or call 800-253-1258 Port Connection Type SAE-12 ports
Port Type SAE-12 ports Weight 4.6 lb ( 2.1 kg)
